Narva 54417 - ANL Fuse Holder with 150A Fuse

Narva • Bolt-down ANL holder • Includes 150A ANL fuse • 32V DC

Product Overview

The Narva 54417 is a heavy-duty ANL fuse holder supplied with a 150A ANL fuse for immediate protection of high-current 12V and 24V circuits. Designed for low resistance connections, the holder provides a secure stud interface for ring lugs and a clear cover for quick inspections. Ideal near the battery to protect feeds for inverters, winches and other high-draw accessories.

Key Features

  • Supplied ready to install with a 150A ANL fuse
  • Accepts standard ANL bolt-down fuses for future value changes
  • Heavy-duty studs accept ring lugs for secure, low resistance terminations
  • Clear protective cover for safety and easy visual checks
  • Base-mount design keeps high-current installs neat and serviceable

Technical Specifications

Brand
Narva
Part Number
54417
Holder Type
ANL bolt-down fuse holder
Included Fuse
ANL 150A
Fuse Compatibility
ANL strip fuses
Voltage Rating
32V DC
Max Current Capability
Up to selected ANL fuse and cabling limits
Terminals
Stud posts for ring lugs
Cover
Clear protective cover included
Mounting
Base mount, near-battery recommended
Pack Contents
1 x ANL holder, 1 x ANL 150A fuse
Warranty
12 months

Selection and Fitment Tips

  • Fuse value: Supplied with 150A. If your equipment specifies another value, refit with the correct ANL rating.
  • Use ANL only: Not compatible with ANS, MIDI or blade fuses.
  • Mount close to source: Install near the battery or power supply to protect the entire downstream cable run.
  • Terminations: Use quality ring lugs, clean contact faces and torque hardware to spec. Recheck after run-in.

Why Choose Narva 54417?

It ships ready to go with a 150A ANL fuse, reducing parts selection and speeding up installs while preserving the flexibility to change fuse value if your system requires it.

Model # 54417
Barcode # 09314464544170

Be The First To Review This Product!

Help other Archer Batteries Pty Ltd users shop smarter by writing reviews for products you have purchased.

Write a product review

What fuse value is included with Narva 54417?
A 150A ANL fuse is included in the pack and pre-sized for many high-current accessories.
Can I change the included 150A fuse to another value?
Yes. The holder accepts standard ANL fuses. Fit the value specified by your equipment and cable size.
Is 54417 compatible with other fuse types like ANS or MIDI?
No. It is designed for ANL bolt-down fuses only.
Where should I mount the holder in the circuit for best protection?
As close to the battery or power source as practical so the entire downstream cable length is protected.
What is the voltage rating and typical system use?
32V DC. Suitable for 12V and 24V automotive and marine systems.
How do I size the fuse correctly if 150A is not suitable for my setup?
Select a fuse that protects the smallest cable in the circuit. The value must not exceed the cable’s continuous ampacity and must suit device inrush and running current.
Does the holder include a cover and what terminations does it use?
Yes, a clear cover is included. The holder uses stud posts for ring lugs on the input and output cables.
What should I check if the included 150A fuse blows during use?
Do not upsize the fuse. Inspect for shorts, damaged insulation, undersized cabling or incorrect equipment settings before refitting.
What is included and what is the warranty period?
One ANL fuse holder, one ANL 150A fuse and a clear cover. Warranty is 12 months.
Any tips for keeping resistance and heat low at the connection?
Use the correct cable gauge, keep contact faces clean and flat, torque hardware to spec and recheck after initial run-in.
