Narva 53810 - ANS Bolt-Down Fuse 80A

Narva • ANS bolt-down strip fuse • 32V DC rating • Approx. 41 x 12 mm • Copper alloy, tin plated

Product Overview

Narva 53810 is an 80A ANS bolt-down fuse for high-current 12V and 24V circuits. The compact ANS footprint delivers low resistance and reliable protection for accessories such as inverters, DC distribution, audio amplifiers and under-bonnet accessory feeds. Install in a suitable ANS holder close to the power source for best protection and minimal voltage drop.

Key Features

  • ANS bolt-down design for secure, low-resistance connections
  • 80A rating suited to medium and high draw circuits
  • 32V DC automotive rating for 12V and 24V systems
  • Copper alloy element with tin plating and inspection window
  • Compact body for engine bay and near-battery mounting
  • Clear amp value marking for quick identification

Technical Specifications

Brand
Narva
Series / Part No.
ANS / 53810
Fuse Type
Bolt-down strip fuse (ANS)
Form Factor
ANS mini-ANL style
Current Rating
80A
Voltage Rating
32V DC
Construction
Copper alloy, tin plated, inspection window
Dimensions
Approx. 41 x 12 mm
Mounting
Bolt-down to ANS holder or block
Pack Quantity
1
Warranty
12 months

Selection and Fitment Tips

  • Match amperage: Replace like-for-like at 80A unless the equipment maker specifies otherwise.
  • Match the holder: Use an ANS compatible holder or block. ANS fuses do not fit MIDI, ANL or blade holders.
  • Location: Mount the holder close to the battery to protect the entire cable run.
  • Repeated blows: If a replacement opens again, diagnose wiring faults or overload rather than increasing the fuse rating.

Why Choose Narva 53810?

Dependable, low-resistance protection in a compact bolt-down format that suits modern accessory installs where space and efficiency matter. Ideal for safeguarding medium to high current circuits while keeping voltage drop low and serviceability simple.

Model # 53810
Barcode # 09314464538100

Be The First To Review This Product!

Help other Archer Batteries Pty Ltd users shop smarter by writing reviews for products you have purchased.

Write a product review

What is Narva 53810?
An 80A ANS bolt-down strip fuse for protecting high-current 12V and 24V automotive and marine circuits.
What is the voltage rating of this fuse?
32V DC. It is suitable for 12V and 24V systems when mounted in an ANS compatible holder or block.
Which holders or blocks are compatible with 53810?
Use Narva ANS holders or distribution blocks such as 54470 and 54472. ANS fuses do not fit blade, MIDI or ANL holders.
Where should the ANS fuse holder be installed in the circuit?
Mount the holder as close to the battery or power source as practical to protect the full cable run from short circuits.
What are typical applications for an 80A ANS fuse?
DC distribution feeds, medium inverters, aftermarket audio amplifiers and other accessories that specify 80A protection. Always follow the equipment maker’s rating.
How do I choose the correct fuse size for my cable?
Fuse to protect the smallest cable in the circuit. Select a rating at or below the cable’s continuous ampacity, allowing for device inrush and running current.
Can I use a higher value if the 80A fuse blows repeatedly?
No. Do not upsize. Repeated operation indicates a fault or overload. Inspect for shorts, damaged insulation, undersized cable or incorrect settings.
Is there a correct orientation when installing an ANS fuse?
ANS fuses are non-directional. Install with clean, flat contact surfaces and tighten hardware securely for a low resistance connection.
What materials are used in the fuse body and element?
Copper alloy element with tin plating and an inspection window in a compact ANS footprint for low resistance and easy visual checks.
How many fuses are in the pack and what is the warranty period?
Pack quantity is 1. Warranty is 12 months.
